B E – ICN7224IPL LCD Display Controller IC – SCIx1055

Name: B E - ICN7224IPL LCD Display Controller IC - SCIx1055
SKU: SS155703
Availability: InStock

See all products from b-e

AED 40.95 VAT included

100 in stock

Compare

Product Code : SS155703 Brand: B E Approved by : [woo_pro_badges_extended]

free delivery
Above AED1000 in UAE
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options

Description

The ICM7224IPL is a 4½ digit LCD Display Controller IC designed for precise digital counting, decoding, and driving applications. It directly interfaces with non-multiplexed liquid crystal displays (LCDs), featuring integrated segment decoders, leading zero blanking, store and reset inputs, and a carry output for cascading multiple ICs to handle more than 4½ digit displays. This IC operates with a low power supply current, making it ideal for battery-operated devices and other low-power applications. It supports a wide operating voltage range from 3V to 5V and is capable of counting frequencies up to 25 MHz, making it suitable for use in frequency counters, tachometers, hour meters, and totalizers.

Features

LCD Display Driver: Directly drives a 4½ digit non-multiplexed liquid crystal display (LCD) for easy display interfacing.
High-Speed Counting: Handles input counting frequencies up to 25 MHz, ideal for applications needing rapid data processing.
Low Power Consumption: Consumes minimal power, with a typical operating current of 10 µA, making it suitable for low-power devices.
Integrated Decoders and Control: Includes segment decoders, leading zero blanking, and store/reset inputs for flexible control options.
Cascading Capability: Can be cascaded to manage counting for 8 or more digits, suitable for advanced counting tasks.
Wide Temperature Range: Supports operation from -20°C to +85°C, ensuring reliable performance in various environments.
