Hoyles AA31110D Six Zone Assistance Call Panel for Toilet or Pool Alarms

Hoyles AA31110D Six Zone Assistance Call Panel for Toilet or Pool Alarms. The Multiguard Assistance Call Panel AA31110D is designed for larger premises that require central indication of alarm calls from toilets, swimming pools, sauna or steam rooms. The system caters for up to 6 zones and is designed to give dual re-assurance at the point of operation. If you require a system with more than 6 zones, simply stack systems together or call us for further options.

The Multizone controller should be sited where staff are located who can respond to an emergency call. An integral PSU and battery are included.
How the Multi Zone Pool / Toilet Alarm system works:
To generate a call the user simply operates the poolside call point
An audible/visual warning is given by the controller and sounder beacons connected to the system identifying the relevant zone
Sounder beacons are silenced by pressing the silence button on the controller
Panel bleeps every 60 seconds and beacons continue to flash until both the activated call point controller are reset
The controller will then reset automaticallyComponents required to build a system

1 x AA31110D Control Panel

At least 1 x WCP-B-11 Call Point per zone

At least 1 x 8581750/HB Sounder Beacon (can be fitted per zone or per system)

1 x LAB35200 Pool Alarm Sign required per Call Point
