Hoyles S1718S Request to Release button with sounder, Red&Green status LEDs
See all products from hoylesAED 723.45 VAT included
Hoyles S1718S Request to Release button with sounder, Red&Green status LEDs. Door Status indicator with sounder, stainless steel vandal resistant push button together with one red and one green LED on a single gang stainless steel plate engraved ‘Press To Release’.
Specifically designed for use with our range of Interguard door interlock controllers. When used with an Interguard, the LEDs indicate the status of the relevant door.
Product Code : SS11020
Brand: Hoyles
Approved by : [woo_pro_badges_extended]
free delivery
Above AED1000 in UAE
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options
Description
Hoyles S1718S Request to Release button with sounder, Red&Green status LEDs. Door Status indicator with sounder, stainless steel vandal resistant push button together with one red and one green LED on a single gang stainless steel plate engraved ‘Press To Release’.
Specifically designed for use with our range of Interguard door interlock controllers. When used with an Interguard, the LEDs indicate the status of the relevant door.Specification
Led Current – 20mA per LED@ 12vdc
Switch Contacts – SPCO 2A @30vdc
Sounder Current – 40mA @ 12vdc
Visual Indication – 1 x red LED 1 x green LED
Integral Sounder Level – 90dB@10cm
Tamper – N/A
Material – 304 Grade Stainless Steel
Dimensions – 86mm x 86mm x 2mm – Facia
38mm galvanised back box supplied
Surface mounted using part no. S0610 listed below
Weight – 0.26kg
IP Rating – IP65 to maintain the IP rating a suitable sealant or gasket for the rear of the plate is required
Approvals – CE and RoHs compliant
