Description

The LCR45 is an enhanced version of the popular LCR40, with new high capacity micro and high resolution ADCs. This passive component impedance meter offers fluid measurements of inductance, capacitance, and resistance, with continuous readings and selectable hold function.

It also features fine resolution for improved performance at low inductance/capacitance/resistance, and auto/manual component type and test frequency. The test frequencies include DC, 1kHz, 15kHz, and 200kHz, with display of component values, complex impedance, complex admittance, and magnitude/phase. The LCR45 includes 2mm plugs and sockets, removable hook probes, a comprehensive illustrated user guide, and a GP23 alkaline battery.

Features

LCR45 is an enhanced version of the popular LCR40, with new high capacity micro and high resolution ADCs
Fine resolution for improved performance at low inductance/capacitance/resistance, and auto/manual component type and test frequency
Passive component impedance meter offers fluid measurements of inductance, capacitance, and resistance, with continuous readings and selectable hold function

Specifications

Brand: Peak Electronic
Model: TMLR0004
Resistance range: 0.0 Ohm to 2 MegOhms, resolution typically 0.2 Ohms, accuracy typically ±1.0% ±0.6 Ohms
Inductance range: 0.0uH to 2H, resolution typically 0.2uH, accuracy typically ±1.5% ±0.6uH
Capacitance range: 0.0pF to 10000uF, resolution typically 0.2pF, accuracy typically ±1.5% ±0.6pF
Impedance accuracy: Typically ±1.5% ±10LSD
Magnitude accuracy: Typically ±1.5% ±10LSD
Phase accuracy: Typically ±5°
Sample rate: 1.5Hz ±0.5Hz.
Open circuit test voltage: ±1.05V
Short circuit test current: ±3.25mA
Test frequencies: DC, 1kHz, 14.925kHz, and 200kHz, ±0.5%
Sine purity: -60dB 3rd harmonic typical
Operating temperature range: 15°C to 35°C (60°F to 95°F)
Battery type: GP23A / V23A / L1028 / MN21 (12V 55mAH type)
Battery life: Typically ~700 operations at <1 minute per operation
Display type: Alphanumeric LCD (not backlit)
