UNI-T – UT612 LCR Meters – TMLR0002

Name: UNI-T - UT612 LCR Meters - TMLR0002
SKU: SS155145
Availability: InStock

See all products from uni-t

AED 846.30 VAT included

100 in stock

Compare

Product Code : SS155145 Brand: UNI-T Approved by : [woo_pro_badges_extended]

free delivery
Above AED1000 in UAE
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options

Description

UT612 LCR meter is used to measure inductance, capacitance and resistance. Advanced features include series/parallel measurement modes, quality factor/loss/phase angle measurements, equivalent/DC resistance measurements and 5 selectable frequencies in AC mode. UT612 can be used in production lines, component inspection and electronic maintenance.

Features

Auto power off
Data hold
Relative mode
USB interface
LCD backlight
Deviation ratio measurement
Comparison function
Calibration funtion
Auto LCR check and measurement

Specifications

Brand: UNI-T
Model: TMLR0002
Output impedance: 120O
Low battery indication: =6.8V
Inductance (H) 20uH~2000H ±(0.5% 5)
Capacitance (F) 200pF~20mF ±(0.5% 5)
Resistance (O) 20O~200MO ±(0.3% 5)
Test frequency (Hz) 100Hz/120Hz/1kHz/10kHz/100kHz v
Operating voltage: 0.6Vrms v
Test parameters: L/C/R/DCR/Q/D/?/ESR v
Power: 9V battery (6F22) or USB
Display: 40mm x 63mm
Product size: 96mm x 193mm x 47mm
Standard accessories: Battery, SMD test clamp, USB interface cable, multi-purpose socket, PC software CD
