Avalon – Fiber LC Pigtail Single Mode APC LSZH, 1mtr – ANPT-SM-LC/APC-1MT
See all products from avalonAED 14.18 VAT included
Avalon – Fiber LC Pigtail Single Mode APC LSZH, 1mtr – ANPT-SM-LC/APC-1MT
Product Code : SS150901
Seller: Security Supplies
Brand: Avalon
Approved by : [woo_pro_badges_extended]
-
free delivery
Above AED1000 in UAE
-
WARRANTY
For 365 days
-
always authentic
Only Reputed Brands
-
EASY PAYMENT
Multiple payment options
Description
Avalon angle polished (APC) pigtails are made by polishing the fiber either at 8 or 9 degrees angle with a radius of curvature between 5mm and 12mm. This fiber has a typical insertion loss of 0.2 dB per connection and APC polished end faces at 65dB minimum return loss. It also passed the international standard of all TIA/EIA-568-B.3, ISO/IEC 11801 OSI performances and complies the UL 1666 flame rating.
Features
- Pass all ISO/IEC 11801 IS1 performance requirements
- Jacketed cable compliant with UL 1666 flame rating
- 100% factory inspected end face geometry in Compliance with TELCODIA GR-326-Core
- Typical Insertion loss per connection is 0.2dB
- APC Polished end faces 65db minimum return loss
Specifications
- Brand: Avalon
- Part: ANPT-SM-LC/APC-1MT
- Fiber Type: Single-mode, Simplex
- Return Loss: 0.45dB
- Mating Durability: 0.2dB typical change, 1000 times
- Operating Temperature: -40 — +75°C
- Storage Temperature: -40 — +85°C
