Hoyles S1705S Call button with re-assurance LED Stainless steel. Flush fitting stainless steel engraved call point with a vandal resistant button and re-assurance LED. This is a non-latching unit with single pole change over contacts. Separate terminals are provided for the LED (red). The LED current limit resistor is provided for 12 vdc operation.

Hoyles Multi function push button c/w LEDs sounder & custom text. Wall mounted button in white ABS complete with a single gang low profile mounting box. This is a MULTI-FUNCTION button that provides DPCO contacts rated at 2A 30vdc for use with equipment such as maglocks and door strikes. The function of the button can be changed. (Momentary, Latching, Delayed latch and Commutate) Two LEDs and an integral sounder are provided. The LEDs indicate when relay is switched, the sounder bleeps as relay changes. The LEDs are available in RED, BLUE, GREEN or YELLOW. This product requires a continuous supply of 12vdc.

Hoyles S348-4-1A 4 way fused output module with 1A fuses. A PCB fuse board module for splitting power from a low voltage power supply (1-30v ac or dc) into 4 individually fused outputs. 1A fuses are provided but can be changed on site as required. Mounting holes for fixing onto nylon pillars are provided.

Hoyles S348-4 4 way fused output module with 500mA fuses. A PCB fuse board module for splitting power from a low voltage power supply (1-30v ac or dc) into 4 individually fused outputs. 500mA fuses are provided but can be changed on site as required. Mounting holes for fixing onto nylon pillars are provided.

Hoyles S1812REG 12-18vdc LDO regulator module 12vdc 500mA output c/w pillars. A 12vdc Low Drop Out Regulator module which will stabalise a PSU output of between 12.5 and 18vdc providing 12vdc at up to 500mA. The Low Drop Out function ensures that even if the input from the PSU drops to 12vdc, a minimum of 11.5vdc will be provided by the module.

Hoyles PSU-12/5AB-8 Eight output 12vdc 5A PSU in a steel enclosure. 12 volt 5A dc general use switched mode power supply with 8 fused outputs. The unit is capable charging a Lead Acid battery (NOT supplied). Output is 13.6vdc. Housed in a steel case, intended for internal use only.All units have protection from AC input surges and transients, under and over AC power, over-heating and over-current, battery-reverse connection and over-current battery charge, substantially removing the need for engineer visits to rectify such problems.

Hoyles PSU-12/2AB 12vdc 2A PSU in a steel enclosure. 12 volt 2A dc general use switched mode power supply. The unit is capable charging a Lead Acid battery (NOT supplied). Output is 13.6vdc. Housed in a steel case, intended for internal use only.All units have protection from AC input surges and transients, under and over AC power, over-heating and over-current, battery-reverse connection and over-current battery charge, substantially removing the need for engineer visits to rectify such problems.

Hoyles H-MAG-Strap Maglock Safety Strap. Security strap for fixing the maglock to the frame of the door to secure the unit from becoming detached.

Hoyles S1736SG Green Overdoor Light stainless steel. Stainless Steel flush fitting overdoor light with16mm Green Jumbo LED. There are separate terminals provided for the LED.The LED current limit resistor is provided for 12 vdc operation.

Hoyles S1736BR Polished Brass Red Overdoor Light. Polished Brass flush fitting overdoor light with16mm Red Jumbo LED. There are separate terminals provided for the LED.The LED current limit resistor is provided for 12 vdc operation.
